PRODUCT DETAILS
Application range:
Quickly and effectively demolish concrete such as crushed house beams and columns, cement poles, etc., while reducing noise and vibration.
Product features:
1.Adopting high-quality wear-resistant steel, with light weight and superior wear resistance;
2.Unique jaw tooth layout design, double layer wear-resistant protection;
3.The structure has undergone load optimization design, balancing the opening size and crushing force.
category | Unit | HD-06 | HD-08 | HD-08S | HD-10 |
Weight | bar | 1450 | 2000 | 2700 | 3300 |
Max Open | mm | 700 | 780 | 880 | 930 |
Cutting Force | ton | 185 | 220 | 300 | 330 |
Crushing Force | ton | 60 | 70 | 100 | 120 |
Working pressure | bar | 350 | 350 | 350 | 350 |
blade length | mm | 180 | 220 | 260 | 260 |
Rotating maximum flow rate | L/min | 28 | 28 | 28 | 28 |
Open/Close | S | 1.5/3 | 2/3 | 2/3 | 2.5/3.5 |
