PRODUCT DETAILS
Application range:
Pre compression and shearing of various low-carbon scrap steel, scrapped car shells, metal structural components, etc.
Product features:
1.Install high-strength wear-resistant alloy steel plates in easily worn areas, effectively extending the service life of the equipment;
2.The shear slider guide rail and shear oil cylinder adopt automatic lubrication to prevent dry friction damage;
3.The intelligent control system provides optimal shear control, reducing the empty stroke of the shear cylinder;
4.The maximum shearing angle can reach 12 degrees, with strong shearing ability.
Model | Parameter | Maximum output | Scissor width | Minimum opening | Shearing capacity | Shear frequency | |||
Shear force | Pressing force | round steel | square steel | steel plate | |||||
Q91Y-400 | 400 | 70 | 3~4 | 1300 | 370 | 65 | 50x50 | 35x800 | 3~4 |
Q91Y-400W | 400 | 100 | 5~6 | 1500 | 440 | 65 | 50x50 | 35x800 | 3~4 |
Q91Y-500 | 500 | 140 | 6~10 | 1700 | 480 | 90 | 80x80 | 50x1000 | 3~4 |
Q91Y-630 | 630 | 140 | 8~12 | 1720 | 580 | 120 | 100x100 | 55x1200 | 3~4 |
Q91Y-700 | 700 | 220 | 12~15 | 1920 | 580 | 140 | 120x120 | 60x1400 | 3~4 |
Q91Y-800 | 800 | 220 | 14~17 | 1920 | 540 | 160 | 140x140 | 70x1600 | 3 |
Q91Y-800W | 800 | 280 | 15~20 | 2130 | 680 | 160 | 140x140 | 70x1900 | 3 |
Q91Y-1000W | 1000 | 300 | 18~23 | 2130 | 680 | 180 | 150x150 | 80x1900 | 3 |
Q91Y-1250W | 1250 | 400 | 20~25 | 2130 | 680 | 210 | 180x180 | 110x1900 | 3 |
Q91Y-1500W | 1500 | 500 | 24~30 | 2130 | 680 | 225 | 200x200 | 130x1900 | 3 |
Q91Y-2000W | 2000 | 700 | 30~38 | 2130 | 680 | 250 | 220x220 | 150x1900 | 3 |
