Applications:
Squeezing various waste metal materials into various shapes of furnace materials is suitable for scrap steel processing and distribution centers, scrap car disassembly centers, casting industries, and so on.
Product features:
1.The lining plate is made of ultra strong wear-resistant plate, with a long service life, which is 3-5 times that of ordinary lining plates;
2.The lock head material is made of high-strength alloy, with a larger locking length and more efficient locking cylinder;
3.The front and rear pin shaft bushings of the door cover oil cylinder and the door cover pin shaft bushings adopt oil-free bearings, which are safer and more reliable;
4. The side pressure head adopts a limit structure up, down, left, and right to protect the side pressure head and side pressure oil cylinder, reducing maintenance costs.
Model | Main cylinder nominal pressure | Workbin(Length* width*height mm) | Package size(mm) | Power(kW) |
Y81-125 | 125 | 1200x700x600 | 300x300 | 15 |
Y81-160 | 160 | 1600x1000x700 | 400x400 | 37 |
Y81-200 | 200 | 1600x1200x700 | 400x400 | 2x22 |
Y81-250 | 250 | 2000x1400x900 | 500x500 | 2x22 |
Y81-315A | 315 | 2500x2000x1200 | 500x500/600x600 | 2x45 |
Y81-315B | 315 | 3000x2500x1200 | 600x600 | 2x45 |
Y81-315C | 315 | 3500x3000x1200 | 600x600/700x700 | 2x45 |
Y81-315D | 315 | 3500x3000x1200 | 600x600/700x700 | 3x45 |
Y81-400A | 400 | 3000x2000x1300 | 600x600 | 2x45 |
Y81-400B | 400 | 3500x3000x1300 | 600x600/700x700 | 3x45 |
Y81-500A | 500 | 3000x2000x1300 | 600x600 | 3x45 |
Y81-500B | 500 | 4000x3000x1300 | 700x700 | 3x45 |
Y81-630 | 630 | 4000x3000x1300 | 700x700/800x800 | 4x45 |
Y81-800 | 800 | 4000x3000x1400 | 700x700/800x800 | 4x45 |
Y81-1000 | 1000 | 4000x3000x1400 | 700x700/800x800 | 5x45 |
