Application range：
The loading, unloading, demolition and construction of some tough Construction waste, and the loading and unloading of scrap iron are mainly the demolition of high-strength sundries.
Product features:
1.Adopting wear-resistant steel, with light weight and strong wear resistance;
2.The pin shaft is made of alloy steel and has an internal oil channel, which has high strength and good toughness;
3.The rotary sorting grab adopts a vertical truck motor rotation system, which rotates 360 ° and has a braking function;
4.The oil cylinder adopts honing tube and high-quality oil seal, which has a long service life and high efficiency.
| category | Unit | HD-00 | HD-01 | HD-02 | HD-04 | HD-06 | HD-08 | HD-10 |
Motor pressure | kg/cm2 | - | 90-110 | 110-120 | 110-120 | 130-150 | 130-150 | 130-150 |
| Motor flow rate | lpm | - | 20-35 | 30-55 | 30-55 | 40-70 | 40-70 | 40-70 |
Cylinder thrust | ton | 2.5 | 4 | 8 | 9 | 15 | 16 | 18 |
| max Mpa | kg/cm2 | 110-140 | 110-140 | 160-200 | 160-200 | 180-230 | 180-230 | 200-250 |
| Operating flow | lpm | 25-40 | 25-40 | 30-55 | 50-100 | 90-110 | 100-140 | 90-150 |
| Suitable excavator | ton | 1-2 | 3-4 | 4-6 | 6-9 | 12-16 | 17-25 | 26-35 |
| Equipment weight | kg | 90 | 200-220 | 310-330 | 440-460 | 900-960 | 1350-1500 | 1700-2100 |
